This 5-axis DMG DMC80U DuoBlock was manufactured in 2011. It features a maximum workpiece diameter of 800 mm and a height of 600 mm, with a load capacity of 800 kg per pallet. The machine is equipped with a dual pallet system and a rapid traverse rate of 60 m/min. If you are looking to get high-quality machining capabilities, consider the DMG DMC80U DuoBlock universal machining centre we have for sale. Contact us for further details.
Overview
- brand: DMG
- year: 2011
- MODEL: DMC80U DuoBlock
- production hours: 34062
- application type: Milling
- Location: Austria
- machine type: Universal Machining Centre
- Available from: 04/01/2027
- control unit brand: HEIDENHAIN
Technical Information - DMG DMC80U DuoBlock
Control Unit
- Control Brand: HEIDENHAIN
- Control Model: iTNC 530
Dimensions
- Machine Weight: 15500 kg
Movement
- C-axis: 360°
- Number of Axes: 5
- X-axis Travel: 800 mm
- Y-axis Travel: 1050 mm
- Z-axis Travel: 800 mm
Technical Specification
- Max. Workpiece Height: 1330 mm
- Spindle Power: 28 kW
- Spindle Speed: 10000 RPM
- Taper Size: SK 50
- Through-spindle Coolant: Yes
- Tool Stations: 120
Additional Information
Control: Heidenhain iTNC 530 3D path control
B-axis Travel: 180° (Universal milling head with controlled B-axis)
Spindle Type: Integrated motor spindle without gearbox
Spindle speed ranges:
Operating mode 1: 0–10,000 rpm
Operating mode 2: 0–800 rpm
Operating mode 3: 0–5,000 rpm
Spindle performance:
Spindle Power (40% Duty Cycle): 28 kW
Spindle Power (100% Duty Cycle): 19 kW
Spindle hours: 34,062 h
Machine on hours: 79,252 h
Spindle: New spindle installed end of 2025
Table Type: NC rotary table with pallet carrier
Pallets Included: 2 pallets
Pallet Clamping Surface: 800 mm x 630 mm
Pallet T-slots: 14 mm per DIN 55201-A2
Pallet Weight: 300 kg per pallet
Maximum Permissible Workpiece Weight on Pallet: 1,400 kg
Maximum Workpiece Height: 1,330 mm
Maximum Workpiece Diameter: 900 mm
Feed Rate (X/Y/Z): 0 - 60,000 mm/min
Axis Acceleration (X/Y/Z): 7 / 6.5 / 6.5 m/s²
Maximum Feed Force (X/Y): 13 kN
Maximum Feed Force (Z): 9 kN
Linear Scale Resolution (X/Y/Z): 0.001 mm
Table Max Torque (40% duty cycle): 5,000 Nm
Table Holding Torque (40% / 100% duty cycle): 5,000 Nm / 3,660 Nm
Table Maximum Rotation: 35 rpm
Pallet Changer Type: Rotary pallet changer
Measuring Probe: Heidenhain TS 649 DMG Infrared probe
Kinematics Verification: 3D quickSET toolkit
Chip Management: Chip conveyor
Mist Extraction System: Oil and emulsion mist extraction system with mechanical filter (1,600 m³/h flow rate)
Cooling Capacity (Machine / Cabinet): 3.3 kW / 1.0 kW
Electrical Connection Data: 86 kVA, 400 V, 50 Hz, Max Nominal Current 124 A
Workpiece dimensions (max): Diameter 800 mm, height 600 mm
Feed force (X/Y/Z): 10 kN
Rapid traverse: 60 m/min
Tool Holder Taper: SK 50 per DIN 69871 Form AD / Form B
Tool Clamping Pull Stud: DIN 69872 Form A / Form B or ISO 7388/2 Typ B
Tool Clamping Mechanism: Mechanical via spring force, hydraulic release
Tool Magazine Capacity: 120 slots (vertical chain magazine)
Delivery: January 2027
Additional equipment
Dual pallet changer system
Internal coolant supply (ICS) with 980 l tank and band filter (40 bar through spindle center)
Clamping hydraulics
Infrared measuring probe
