ERMAKSAN SPEED-BEND PRO 51000 X 400 Bending machine

This ERMAKSAN SPEED-BEND PRO 51000 X 400 Bending machine was manufactured in the year 2017 in Turkiye. It has 7 axis. The machine has a pressing force of 4000 kN.

Overview

brand: ERMAKSAN
year: 2017
MODEL: SPEED-BEND PRO 51000 X 400
application type: Bending
Location: Germany
machine type: Bending machines
availability: Sold
GINDUMAC ID: DE-BEN-ERM-2017-00001

Technical Information

General Data

Measurements width: 7000 mm
Measurements depth: 3000 mm
Measurements height: 4000 mm
Machine weight: 35000 kg

Main drive

Pressing force: 4000 kN
Stroke: 375 mm
Number of axis: 7

Movement

X-AXIS Movement: 800 mm

Table

Height adjustment: 900 mm

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Column projection: 510 mm
- - Crowning: controlled
- - Rear safety system: fisseler/m2000 sick
- - Front safety system: akas laser
- - Safety guard: lateral with switch
- - Foot switch: double pedal
- - Hydraulics: hörbiger
- - Y1/y2 axes: synchronized (+/- 0. 01 mm)
- - Press pressure: automatic adjustment
- - Upper tool punch: 6. 100/135/85/r0,8
Qualitative Machine Benefits:
- - Die block: 200x200 v - 60-80-100-140 mm
- - Cooling: oil cooler
- - Adapter rail for 60 mm die: l=5000 mm
- - Hydraulic clamping: promecan type
- - Support arms: 4 pieces on linear guide
- - Backgauge: 4-axis

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
