Front view of FELDER Tempora 45.03 LX machine

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

FELDER Tempora 45.03 LX

Photo Gallery

FELDER - Tempora 45.03 LXDE-EDG-FEL-2019-00001

Sold

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Wood Working
➤ Used FELDER Tempora 45.03 LX For Sale | gindumac.com

This FELDER Tempora 45.03 LX edgebander was manufactured in 2018. It features a joining unit with a diamond cutter, a cross-cut saw unit with an adjustable angle, and a corner processing unit suitable for edge thicknesses up to 3 mm. The gluing unit is Teflon-coated and supports both EVA and PUR glues. Ideal for enhancing workshop capabilities, the FELDER Tempora 45.03 LX edgebander we have for sale. Contact us for further details regarding this edgebander.

Overview

brand: FELDER
year: 2018
MODEL: Tempora 45.03 LX
application type: Edge Banding
Location: Germany
machine type: Edgebander

Technical Information - FELDER Tempora 45.03 LX

General Data

Machine weight: 1350 KG

Additional Information

Additional equipment

Upper and lower radius scraper blades
polishing units
neumatic insertion lock for workpiece distance monitoring
Lighting equipment: LED for Tempora 45.03L
Optional: extraction unit with the complete pipework

Machine Benefits

Qualitative Machine Benefits

Rcd to be connected upstream: type b, tripping current 300ma
Segmented, rubberized support pads with quick-change system

Technical Machine Benefits

Electrical: 3×400v, 50hz
Speed: 9 m/min
Drive motor: 0. 75 kw (s6)
Minimum workpiece length: 140 mm
Joining unit: 1. 5 kw, 12,000 rpm, max. Chip removal 2 mm, diamond cutter d-80 x 49 mm
Cross-cut saw unit: high-frequency motor with 0. 35 kw, 12,000 rpm, adjustable cutting angle 0° to 10°
Corner processing unit: for edge thicknesses of 0. 4-3 mm, min. Workpiece length 270 mm
Flush and radius trimming unit: positioning-controlled, 0. 75 kw, 12,000 rpm (both top and bottom)
Gluing unit: teflon-coated, for 1. 5 kg eva granulate, synchronized glue roller, suitable for pur glue

Extra Information

Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
