Front view of HAAS VF-4SS  machine

HAAS - VF-4SSCZ-MIL-HAA-2018-00001

Sold

Do you have further questions? Contact us.

sales contact

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

whatsapp
Click to chat on WhatsApp

This 3-axis vertical machining centre was manufactured in 2018. The HAAS VF-4SS-EU features cutting-edge options like a spindle speed of up to 12,000 rpm and a robust table supporting loads up to 794 kg. Precision is maintained with linear rolling prestressed axle guides and an ISO40 / DIN69871/A drive type, enhancing the reliability of production processes. The CNC control system, compatible with FANUC, offers streamlined operation, which makes buy this HAAS VF-4SS-EU vertical machining centre a strategic addition to any manufacturing fleet. Contact us for more information.

Overview

  • brand: HAAS
  • year: 2018
  • MODEL: VF-4SS
  • application type: Milling
  • Location: Czech Republic
  • machine type: Vertical Machining Centre
  • availability: Sold
  • control unit brand: HAAS

Technical Information - HAAS VF-4SS

General Data

  • Machine weight: 5950 kg

Control Unit

  • Brand: HAAS

Main drive

  • Number of spindles: 2
  • Spindle speed range: 12000 1/MIN
  • Number of axis: 3

Movement

  • X-AXIS Working Feed: 21.2 m/min
  • X-AXIS Rapid traverse: 35.6 m/min
  • Y-AXIS Working Feed: 21.2 m/min
  • Y-AXIS Rapid traverse: 35.6 m/min
  • Z-AXIS Working Feed: 21.2 m/min
  • Z-AXIS Rapid traverse: 35.6 m/min

Table

  • Table load: 794 kg

    Additional Equipment

    • - linear rolling prestressed axle guide
    • - 15" LCD color monitor
    • - electronic micro scroll wheel
    • - module for quick detection of power failure
    • - 2 hand guns for air and liquid cleaning
    • - hanging tool shelf and notebook holder
    • - feet for setting up the machine
    • - WIP-S Renishaw probes
    • - 32GB extended memory
    • - TSC ready

    Additional Information

      Machine Benefits

      • Technical Machine Benefits:
        • - 3-axis version
        • - Working tracks x,y. Z = 1,270 x 508 x 635 mm
        • - Dimensions of the work table 1321 x 457 mm
        • - Number/dimension/spacing t-slot = 5 / 16mm / 80 mm
        • - Distance of the entire drive / surface of the table = 107-742 mm
        • - Iso40 / din69871/a drive type
        • - Max. Drive speed 12,000 rpm // max. Output 22. 4 kw, inline direkt drive drive // max. Spindle torque 122 nm
        • - 208 liter coolant tank with pump // cooling block with adjustable nozzles around the fan
        • - Electric connected 3x400v/50hz, 28kva
        • - Central automatic grease lubrication (spindle oil) // operating memory 1 gb // usb and ethernet communication interfaces
      • Qualitative Machine Benefits:
        • - Hours: run time: 9309h, feed cutting time: 2113h > excellent condition!
        • - Cnc control system haas in destination, compatible with fanuc
        • - Solid cast iron construction
        • - Temperature stabilization of the spindle , direct threading
        • - Lighting of the working area of the machine
        • - Ce version of the machine
        • - High speed machining

    *There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
