HAAS VM-6

HAAS - VM-6FR-MIL-HAA-2015-00001

Sold

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
HAAS VM-6 Vertical machining center

This HAAS VM-6 Vertical machining center was manufactured in the United States in the year 2015. This 3 axis machine is operated through a control unit of the same brand. It has a spindle speed up to 12000 rpm. It has a 1620 x 710 mm table with a capacity of 1800 kg of table load. Machine in very good condition.

Overview

brand: HAAS
year: 2015
MODEL: VM-6
application type: Milling
Location: France
machine type: Vertical Machining Centre
availability: Sold
control unit brand: HAAS

Technical Information - HAAS VM-6

General Data

Machine weight: 11000 kg

Control Unit

Brand: HAAS

Main drive

Spindle speed range: 12000 1/MIN
Spindle motor power: 22.4kw
Number of axis: 3

Movement

X-AXIS Movement: 1620 mm
Y-AXIS Movement: 810 mm
Z-AXIS Movement: 760 mm

Table

Outer length: 1620 mm
Outer width: 710 mm
Table load: 1800 kg

Media

Chip conveyor: Yes

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Tapered spindle: bt 40
- - Cooling through the spindle: yes
- - Spindle nose / table distance 860 mm
- - Longitudinal travel 1620 mm
- - Cross travel y 810 mm, vertical travel z 760 mm
- - Rotary table (4th axis) no
Qualitative Machine Benefits:
- - Machine in perfect working order

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
