HAITIAN - ZE1900 RO-INJ-HAI-2019-00002
Do you have further questions? Contact us.
Borja Garcia
+34 679 019 350
b.garcia@gindumac.com
- GINDUMAC
- Products
- Plastics Processing Machinery
- ➤ Used HAITIAN ZE1900 For Sale | gindumac.com
This HAITIAN ZE1900 was manufactured in 2019. It features a clamping force of 1900 kN, a maximum injection volume of 412 cm³, and a screw diameter of 50 mm. The machine includes a robot interface (Euromap 67) and is still in production with excellent condition. If you are looking to get high-quality injection molding capabilities, consider the HAITIAN ZE1900 machine we have for sale. Contact us for more information about this machine.
Overview
- brand: HAITIAN
- year: 2019
- MODEL: ZE1900
- production hours: 20270
- application type: Injection Moulding
- Location: Romania
- machine type: Electrical Injection Moulding Machine
Technical Information - HAITIAN ZE1900
Dimensions
- Machine Height: 2160 mm
- Machine Length: 5871 mm
- Machine Weight: 9300 kg
Technical Specification
- Clamping Force: 1900 kN
- Screw Diameter: 50 mm
Additional Information
Maximum injection volume: 412 cm³
Mold height (min/max): 200 / 550 mm
Opening stroke: 1,020 mm
Platen dimensions (W × L): 790 × 840 mm
Tie-bar distance: 570 × 520 mm
Motor power: 45 kW
Heater power: 20.2 kW
Electrical connection pins: 32
Injection nozzle radius (tip): R10
Centering ring diameter: 160 mm
Operating hours: 20,207 h
Condition: Excellent
Status: In production
Additional equipment
Robot (included)
Robot interface: Euromap 67
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
