This HAITIAN ZE2300 was manufactured in 2019. It features a clamping force of 2300 kN, a platen opening stroke of 1150 mm, and a screw diameter of 55 mm. Equipped with a robot and Euromap 67 interface, it remains in excellent condition and is still in production. If you are looking to get high-quality injection moulding capabilities, consider the HAITIAN ZE2300 machine we have for sale. Contact us for more information.
Overview
- brand: HAITIAN
- year: 2019
- MODEL: ZE2300
- production hours: 31732
- application type: Injection Moulding
- Location: Romania
- machine type: Electrical Injection Moulding Machine
Technical Information - HAITIAN ZE2300
Dimensions
- Machine Height: 2160 mm
- Machine Length: 5871 mm
- Machine Weight: 12000 kg
Technical Specification
- Clamping Force: 2300 kN
- Screw Diameter: 55 mm
Additional Information
Platen opening stroke: 1150 mm
Minimum mould height: 220 mm
Maximum mould height: 600 mm
Tie-bar distance: 620 × 620 mm
Platen dimensions: 920 × 920 mm
Centering ring diameter: 160 mm
Maximum injection volume: 570 cm³
Injection nozzle radius (tip): R10
Motor power: 47 kW
Heater power: 25 W
Number of electrical connection pins: 32
Robot interface: Euromap 67
Operating hours: 31,732 h
Condition: Excellent
Status: In production
Additional equipment
Robot (installed)
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
