This 6-axis RICO PRCN Synchro 30135 was manufactured in 2013. It features a press force of 1350 kN and a bending length of 3100 mm. The machine is equipped with a powerful 11 kW motor and offers advanced CNC controlled bending aid systems. If you are looking to get high-quality bending capabilities, consider the RICO PRCN Synchro 30135 press brake we have for sale. Contact us for further details.
Overview
- brand: Other
- year: 2013
- MODEL: PRCN Synchro 30135
- production hours: 1127
- application type: Bending
- Location: Germany
- machine type: Press Brake
- control unit brand: DELEM
Technical Information - Other PRCN Synchro 30135
Control Unit
- Control Brand: DELEM
- Control Model: DA-66T CNC
Dimensions
- Machine Height: 2550 mm
- Machine Length: 3640 mm
- Machine Weight: 10200 kg
- Machine Width: 1750 mm
Movement
- Number of Axes: 6
Technical Specification
- Bending Length: 3100 mm
- Max. Stroke: 200 mm
- Pressing Force: 1350 Kn
Additional Information
Distance Between Side Frames: 2600 mm
Motor Power: 11 kW
Open Height: 400 mm
Throat Depth: 400 mm
Approach Speed: 200 mm/s
Working Speed: 0–10 mm/s
Return Speed: 150 mm/s
X-Axis Speed: 500 mm/s
X-Axis Positioning Accuracy: ±0.05 mm
R-Axis Travel: 150 mm
R-Axis Speed: 170 mm/s
R-Axis Positioning Accuracy: ±0.20 mm
R-Axis Repeatability: ±0.20 mm
Z1-Z2 Travel Range: approx. 2500 mm
Z1-Z2 Speed: 2000 mm/s
Z1-Z2 Positioning Accuracy: ±0.10 mm
Z1-Z2 Repeatability: ±0.10 mm
Laser Safety System: Fiessler AKAS LC-II F
Hydraulic System: Hoerbiger
Product and Tool Memory: 64 MB
Interfaces: 2 × USB, RS232C, Network Interface, PLC Interface
Independent Z1-Z2 Finger Positioning: Yes
Free-Moving Right Backgauge Finger: Yes
Right Finger Travel Range: 200 mm
Relative Right Finger Adjustment: +100 mm / -100 mm
Pneumatic Sheet Support Arms with Ball Rollers: Yes
CNC Controlled Bending Aid System: ACF1
Number of Motorized Bending Aids: 2
Bending Aid Load Capacity: approx. 150 kg per unit
Bending Aid Support Range: approx. 900–1500 mm
Bending Aid Width per Arm: approx. 350 mm
Bending Aid Height Adjustment: ±60 mm
Bending Aid Depth Adjustment: 0–60 mm
Bending Aid Accuracy: ±0.2 mm
Support Arm Working Area: 500 mm
Maximum Box Height with Raised Tooling System: up to 240 mm
Tool Clamping: Pneumatic Upper Clamping
Operating Hours: approx. 11,270 h
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
