- ➤ Used SCM Abricht/ Dickenhobelmaschine | For Sale
This SCM Abricht/ Dickenhobelmaschine was manufactured in 2020. It features a working width of 520 mm and an adjustable thicknessing height from 3 mm to 250 mm. The machine includes a "TERSA" cutter block system with 4 disposable knives and offers four feed speeds. Consider the opportunity to buy this SCM Abricht/ Dickenhobelmaschine wood planer. Contact us for further details.
Overview
- brand: SCM
- year: 2020
- MODEL: Fs 7
- application type: Planing
- Location: Germany
- machine type: Wood Planer
Technical Information - SCM Fs 7
Technical Specification
- Spindle Power: 9 kW
- Spindle Speed: 5000 RPM
- Working Length: 2310 mm
- Working Width: 520 mm
Additional Information
Working width: 520 mm
Thicknessing height: 3–250 mm (adjustable)
Surface table length: 2,310 mm
Feed speeds: 5 / 8 / 12 / 18 m/min
Cutter block: TERSA system, 4 disposable knives, 120 mm diameter
Control unit: READY electronic control
Programmability: up to 99 programs
Axis control: motorized vertical adjustment of thicknessing table with digital position display
Power-assisted changeover: pneumatic/hydraulic automatic lifting of surfacing tables
Supply voltage: 400 V, 3-phase, 50 Hz
Main motor: 9 kW (12 HP) with automatic star-delta start
Braking: automatic electronic motor brake
Suction: 120 mm extraction outlets for surfacing and thicknessing
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
