Front view of CHIRON FZ 15K S FA  machine

CHIRON - FZ 15K S FAIT-MIL-CHI-2009-00001

49,000 €
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

whatsapp
Click to chat on WhatsApp

This 5-axis CHIRON FZ 15K S FA vertical machining centre was manufactured in 2009. It features a HSK-A63 taper, complemented by a swivel-roundtable with dual 280 mm clamping surfaces. The machine includes a 48-station chain magazine and an internal cooling unit with a 70 bar filter. Ideal for complex machining tasks, the CHIRON FZ 15K S FA represents a robust addition to any production line. Reach out for more information.

Overview

  • brand: CHIRON
  • year: 2009
  • MODEL: FZ 15K S FA
  • application type: Milling
  • Location: Italy
  • machine type: Vertical Machining Centre
  • availability: Immediately
  • control unit brand: SIEMENS

Technical Information - CHIRON FZ 15K S FA

General Data

  • Measurements width: 4000 mm
  • Measurements depth: 4000 mm
  • Measurements height: 3000 mm
  • Machine weight: 9000 kg

Control Unit

  • Model: 840D - Powerline
  • Brand: SIEMENS

Main drive

  • Spindle speed range: 12000 rpm 1/MIN
  • Tool taper: HSK-A63
  • Number of axis: 5

Movement

  • X-AXIS Movement: 730 mm
  • Y-AXIS Movement: 400 mm
  • Z-AXIS Movement: 425 mm
  • A-AXIS Movement: -110°/+110° MM
  • C-AXIS Movement: 360° MM

Workpiece

  • Workpiece weight: 15 kg

Tools

  • Max weight: 5 kg
  • Max tool diameter: 82 mm
  • Max tool length: 250 mm

Media

  • Oil water separator: Yes
  • Chip conveyor: Yes
  • Internal cooling: Yes

    Additional Equipment

    • - Position sensor: Direct Scales in all Axis
    • - Chip management: Chip flushing and chip conveyor
    • - Cooling management: Internal cooling unit with filter, 70 bar
    • - Workpiece measurement: Preparation Touchprobe, Renishaw
    • - Oil mist separation: Electrostatic extraction, LTA
    • - Fire-extinguishing system: Kraft + Bauer
    • - Automation: Automatic door
    • - Further Accessory: Rinsing pistol

    Additional Information

      Machine Benefits

      • Technical Machine Benefits:
        • - Clamping surface: 2x roundtable ø280 mm
        • - Comprehensive cooling management with internal cooling unit and 70 bar filter
        • - Advanced chip management with chip flushing and chip conveyor
        • - Direct scales in all axes for precise positioning
        • - Electrostatic oil mist extraction for a cleaner working environment
        • - Fire-extinguishing system for enhanced safety
        • - Automation features including an automatic door
        • - Chain magazine: 48 stations
        • - Spindle technology: motorspindle
        • - Nc-swivel-roundtable technology: swinging bridge with 2 roundtables

      Extra information

      • - Machine still under power

    *There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
