DOOSAN - PUMA V400-2SPIT-TUR-DOO-2007-00005

Name: DOOSAN PUMA V400-2SP
Brand: DOOSAN
SKU: IT-TUR-DOO-2007-00005
Price: 40000 EUR
Availability: InStock

40,000 €

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used DOOSAN PUMA V400-2SP For Sale | gindumac.com

Vertical turning machine manufactured in 2007. This DOOSAN PUMA V400-2SP features a maximum turning diameter of 400 mm and a turning height of 400 mm. It includes dual 8/12-station turrets and operates with a FANUC Series 18i-TB CNC control. If you are looking to get high-quality turning capabilities, consider the DOOSAN PUMA V400-2SP machine we have for sale. Contact us for further details regarding this machine.

Overview

brand: DOOSAN
year: 2007
MODEL: PUMA V400-2SP
application type: Turning
Location: Italy
machine type: Vertical Turning Machine
control unit brand: FANUC

Technical Information - DOOSAN PUMA V400-2SP

Control Unit

Control Brand: FANUC
Control Model: Series 18i-TB

Dimensions

Machine Weight: 10000 kg

Movement

Number of Axes: 2
X-axis Travel: 220 mm
Z-axis Travel: 400 mm

Technical Specification

Driven Tools: No
Spindle Power: 22 kW
Spindle Speed: 3000 RPM

Additional Information

Control feature: Independent dual-channel operation (Right & Left)
Machine condition: Good working condition, currently under power
Max. turning diameter: Ø 400 mm
Max. turning height: 400 mm
Max. swing over bed: Ø 490 mm
Chuck size: 315 mm
Spindle nose: A2-8
Turrets: 2 × 8/12-station turrets
Guideways: Box guideways (heavy duty)

Additional equipment

Rear/side chip conveyor with cart
High-pressure coolant system

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
