This 7-axis Gildemeister Twin 41 horizontal turning machine was manufactured in 2006. Ideal for precision and complex turning operations, it offers robust performance and reliability. Consider the opportunity to buy this Gildemeister Twin 41 horizontal turning machine. Contact us for more information.
Overview
- brand: Gildemeister
- year: 2006
- MODEL: Twin 41
- application type: Turning
- Location: Germany
- machine type: Horizontal Turning Machine
- availability: Immediately
- control unit brand: SIEMENS
Technical Information - Gildemeister Twin 41
Control Unit
- Brand: SIEMENS
- Model: 840 D
Main drive
- Spindle speed range: 7000 rpm 1/MIN
- Number of axis: 7
Additional Equipment
- - Double spindle version
- - Y-axis
- - Main and counter spindle
- - Collet chuck
- - 1 attached tool axial
- - 1 attached tool radial
- - Belt filter system
- - Loading magazine FMB Turbo 10-72 XT
Additional Information
- Technical Machine Benefits:
- - Rotation diameter 145 mm
- - Chuck diameter (spindle 1 + 2): 140 mm
- - Longitudinal slide travel z1, z2, z3: 320 mm, 345 mm, 380 mm
- - Vertical slide travel y1: +/- 30 mm
- - Longitudinal spindle travel z3: 380 mm
- - Tool stations: 12, all stations attached
- - Shank diameter: 25 mm
- - Speed of the attached tools: 6000 rpm
- - C-axis: 2000 rpm
- - Pitch: 0. 001°
- - Machine still under power
Machine Benefits
Extra information
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
