➤ Used IMA NOVIMAT I /G80/390/R3 For Sale | gindumac.com

This IMA NOVIMAT I /G80/390/R3 edgebander was manufactured in 2013. It features dual 4.5 kW motors at 150 Hz, achieving speeds up to 9000 rpm. Capable of handling edge heights from 14 to 65 mm and roll diameters up to 850 mm, it's ideal for precise edgebanding needs. Consider the opportunity to buy this IMA NOVIMAT I /G80/390/R3 edgebander. Contact us for more information about this machine.

Overview

brand: IMA
year: 2013
MODEL: NOVIMAT I /G80/390/R3
application type: Edge Banding
Location: Germany
machine type: Edgebander

Technical Information - IMA NOVIMAT I /G80/390/R3

Main drive

Spindle speed range: 12000 rpm 1/MIN

Additional Information

Additional information

Motor Power: 2 x 45 kW, 150 Hz
Motor Speed: 9000 rpm
Power Supply: 230 V
Heating Power: 6 x 500 watts
Adjustment Range: Vertical approx. 17 mm, Horizontal approx. 30 mm
Stroke: Max. 8 mm
Roll Diameter: Max. 850 mm
Edge Height: 14 – 65 mm
Workpiece Projection: Min. 30 mm + edge thickness, Max. 80 mm including edge thickness
Workpiece Length: Min. 130 mm
Workpiece Gap: Min. 300 mm
Workpiece Distance: Min. 990 mm
Workpiece Thickness: Min. 8 mm, Min. 12 mm with tracing wheel, Max. 80 mm
Single Tracing Workpiece Projection: Min. 30 mm
Double Tracing Workpiece Projection: Min. 38 mm for max. 4 profiles, Max. 50 mm
Cutter Head Diameter: 125 mm
Motor Shaft: 30 x 68 mm diameter
Internal Thread: M16, Depending on motor, left or right
Cutting Cross-section Motor Power: 0.20 kW, 200 Hz 400 V, 12000 rpm for max. 195 mm², Option: 0.66 kW, Extension to max. 1100 mm²
Tool Diameter: 160 mm / 48 teeth
Swivel Range: 0 and 25 degrees
Workpiece Speed: Max. 30 m/min for an edge cross-section of 3 x 45 mm
Edge Overhang: Top edge, max. 3 mm, Bottom edge, max. 2 mm for straight edges
Edge Material: Edge, max. 4 mm for wood and plastic; Aluminum, max. 3 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
