CNC machine, model Challenger 1500, side view showing control panel and workspace with metal shavings.

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

Johnford VMC-850A

Photo Gallery

Johnford - VMC-850AES-MIL-JOH-1998-00002

Sold

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used Johnford VMC-850A For Sale | gindumac.com

This 3-axis Johnford VMC-850A was manufactured in 1998. It features a robust 800 mm X-axis, 500 mm Y-axis, and 610 mm Z-axis travel, with a table size of 1000 x 500 mm supporting up to 400 kg. Equipped with a BT-40 spindle, achieving speeds up to 8000 rpm, and an automatic tool changer for 24 tools. Ideal for precise and efficient machining. Contact us for more information about this machine.

Overview

brand: Johnford
year: 1998
MODEL: VMC-850A
application type: Milling
Location: Spain
machine type: Vertical Machining Centre
control unit brand: FANUC

Technical Information - Johnford VMC-850A

Control Unit

Control Brand: FANUC

Dimensions

Machine Depth: 2200 mm
Machine Height: 2700 mm
Machine Length: 2350 mm
Machine Weight: 6000 kg

Movement

X-axis Travel: 800 mm
Y-axis Travel: 500 mm
Z-axis Travel: 610 mm

Additional Information

Workpiece capacity: 400 kg (max on table)
Table size: 1000 × 500 mm
Tool changer: Automatic arm style (24 tools typical)
Max tool diameter: 100 mm (limited by adjacent tools)
Max tool length: 320 mm
Spindle taper: BT‑40 (standard)
Max spindle speed: up to 8000 rpm
Spindle drive power: 5.5–7.5 kW
Rapid traverse: 30 m/min (X/Y), 20 m/min (Z)
Coolant system with nozzles
Spindle air blast
LED working lights

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
