Front view of Mazak Integrex 100 IV ST  machine

Mazak - Integrex 100 IV STIT-TUR-MAZ-2011-00001

90,000 €
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

whatsapp
Click to chat on WhatsApp

This 4-axis Mazak Integrex 100 IV ST was manufactured in 2011. It features a main spindle with a 6" hydraulic chuck, 4,000 rpm max speed, and 30 kW power. The second spindle matches these capabilities. Its milling spindle can reach up to 20,000 rpm. Includes a high-speed ATC with a 20-tool capacity, expandable to 120. Ideal for single-setup machining with its heavy-duty construction and MAZATROL MATRIX CNC control. Contact us for more information about this machine.

Overview

  • brand: Mazak
  • year: 2011
  • MODEL: Integrex 100 IV ST
  • application type: Turning
  • Location: Italy
  • machine type: Horizontal Turning Machine
  • availability: Immediately
  • control unit brand: MAZATROL

Technical Information - Mazak Integrex 100 IV ST

Control Unit

  • Brand: MAZATROL
  • Model: Matrix

Additional Information

    Machine Benefits

    • Technical Machine Benefits:
      • - Chuck type: 6" hydraulic chuck with bar capacity max /spindle speed: 4000 rpm max /power: 30 kw / 22 kw continuous/ max torque: 500 nm /spindle nose: a2-8/ acceleration time: 5. 1 seconds
      • - Type: 6" hydraulic chuck max speed: 4000 rpm max power: 26 kw / 22 kw continuous /max torque: 724 nm /spindle nose: a2-8 /acceleration time: 2. 7 seconds
      • - Max speed: up to 20000 rpm (optional) /max power: 18. 5 kw/ max torque: 119 nm/ taper type: km63, capto c6, bt40
      • - X-axis: 410 mm/ y-axis: ±70 mm (total 140 mm) /z-axis: 805 mm/ b-axis (milling head): 210° rotation/ c-axis (spindle): 0. 0001° resolution (full contouring)
      • - Max turning diameter: approx. ø545 mm/ max turning length: approx. 600 mm
      • - Tool capacity: 20 tools standard, expandable to 120 /changer type: high-speed cam-driven system
      • - Heavy-duty construction with linear guides “done in one” multi-tasking concept for single-setup machining/ cnc control: mazatrol matrix with 3d simulation/ intelligent thermal shield for automatic thermal compensation

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
