MIKRON - BTM 2000DE-GRI-MIK-1994-00001

Name: MIKRON BTM 2000
Brand: MIKRON
SKU: DE-GRI-MIK-1994-00001
Price: 14500 EUR
Availability: InStock

14,500 €

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used MIKRON BTM 2000 For Sale | gindumac.com

This MIKRON BTM 2000 surface grinding machine was manufactured in 1994. It features an impressive X-axis travel of 2,000 mm, Y-axis travel of 800 mm, and Z-axis travel of 1,000 mm. The machine has a maximum table load of 3,500 kg and a spindle speed of up to 4,000 rpm. If you are looking to get high-quality surface grinding capabilities, consider the MIKRON BTM 2000 machine we have for sale. Contact us for further details.

Overview

brand: MIKRON
year: 1994
MODEL: BTM 2000
application type: Grinding
Location: Germany
machine type: Surface Grinding Machine
control unit brand: HEIDENHAIN

Technical Information - MIKRON BTM 2000

Control Unit

Control Brand: HEIDENHAIN
Control Model: TNC 407

Movement

Number of Axes: 3
X-axis Travel: 2000 mm
Y-axis Travel: 800 mm
Z-axis Travel: 1000 mm

Additional Information

- Not fully functional; error message "Grober Positionierfehler" (Gross positioning error);

- Electronic Handwheel: Heidenhain HR 330

- Maximum Table Load: 3,500 kg

- Rapid Traverse (X/Y/Z): 15 m/min each

- Milling Head: Manual universal milling head

- Spindle Speed: Up to 4,000 rpm (min⁻¹)

- Tool Taper / Holder: ISO 40 according to DIN 2080

- Linear Measuring System: Direct Heidenhain LS 106 C linear scales in X, Y, and Z

- Drive Technology: Siemens SIMODRIVE 611

- Working Area Enclosure: Sliding doors and strip curtain / lamellar splash guard

- Cooling / Auxiliary: Separate cooling unit / aggregate

- Maintenance History: Y/Z-slides overhauled by a specialized company approx. six years ago

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.

** The default scope of delivery includes the machine only. Accessories and peripheral equipment will be confirmed through binding agreements during the purchasing process.
