Okuma - MA 600IT-MIL-OKU-2005-00002
Do you have further questions? Contact us.
Borja Garcia
+34 679 019 350
b.garcia@gindumac.com
- GINDUMAC
- Products
- Machine Tools
- ➤ Used Okuma MA 600 For Sale | gindumac.com
This 4-axis Okuma MA 600 horizontal machining center was manufactured in 2005. It features a powerful CNC P 200 control, with a maximum spindle speed of 6000 RPM and a spindle torque of 606 Nm. The machine includes a 100-tool station with chain management and rapid feeds up to 60 m/min in X, Y, Z axes. Dimensions include a maximum height of 3.28 m and a weight of 24,000 kg. The opportunity to buy this Okuma MA 600 horizontal machining center is significant. Contact us for further details.
Overview
- brand: Okuma
- year: 2005
- MODEL: MA 600
- application type: Milling
- Location: Italy
- machine type: Horizontal Machining Centre
- availability: Immediately
Technical Information - Okuma MA 600
General Data
- Measurements width: 6110 MM
- Measurements depth: 3380 MM
- Measurements height: 3280 MM
- Machine weight: 24000 KG
Main drive
- Spindle speed range: 6000 1/MIN
- Spindle motor power: 30/22 kW
- Tool taper: BT 50
- Main motor power: 50 kVA
- Number of axis: 4
Movement
- X-AXIS Movement: 1000 mm
- X-AXIS Working Feed: 60000 mm/min
- X-AXIS Rapid traverse: 60 m/min
- Y-AXIS Movement: 900 mm
- Y-AXIS Working Feed: 60000 mm/min
- Y-AXIS Rapid traverse: 60 m/min
- Z-AXIS Movement: 1000 mm
- Z-AXIS Working Feed: 60000 mm/min
- Z-AXIS Rapid traverse: 60 m/min
Table
- Min distance between vertical spindle and table: 50 mm
- Max distance between vertical spindle and table: 950 mm
Tools
- Max weight: 25 kg
- Max tool length: 450 mm
Additional Equipment
- - Consep 2000 chip conveyor
Additional Information
- Technical Machine Benefits:
- - Ikz: 20 bar
- - Table drive motor power: 1. 9 kw
- - Table indexing time (90° - 180°): 2. 0 – 3. 0 sec
- - Pallet change time: 7 sec
- - Distance between spindle nose/table center: 70-1070 mm
- - Front bearing diameter: 100 mm (60 mm)
- - Max spindle torque: 606 nm
- - Tool change time (tool/tool): 1. 9 sec
- - Tool change time (chip/chip): 4. 4 sec
- - Max adjacent tool diameter: 140 mm (100 mm)
- Qualitative Machine Benefits:
- - Max non-adjacent tool diameter: 240 mm
- - Compressed air pressure: 4-6 bar
- - Refrigeration through spindle: 20 bar
- - Probe preparation zero offset
- - Presetting on board mechanical table
- - Machine still under power
Machine Benefits
Extra information
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
