DMG 635 V Ecoline vertical machining centre, front view with control panel, showing machining area and modern design.
DMG 635 V Ecoline vertical machining centre, front view with control panel, showing machining area and modern design.

DMG - 635 V EcolinePL-MIL-DMG-2015-00005

45,000 €
gindumac price
(Ex works)
get an official quote
Visit the machine
make a counteroffer
Download PDF

Do you have further questions? Contact us.

sales contact

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

whatsapp
Click to chat on WhatsApp

This 3-axis DMG MORI ecoMill 635 V was manufactured in 2015. It features an X-axis travel of 635 mm, Y-axis travel of 510 mm, and Z-axis travel of 460 mm. The machine has a robust table size of 900 x 560 mm and a maximum table load of 600 kg. If you are looking to get high-quality machining capabilities, consider the DMG MORI ecoMill 635 V vertical machining centre we have for sale. Contact us for further details.

Overview

  • brand: DMG
  • year: 2015
  • MODEL: 635 V Ecoline
  • production hours: 1748
  • application type: Milling
  • Location: Poland
  • machine type: Vertical Machining Centre
  • control unit brand: SIEMENS

Technical Information - DMG 635 V Ecoline

Control Unit

  • Control Brand: SIEMENS
  • Control Model: SINUMERIK control (828D)

Dimensions

  • Machine Weight: 3900 kg
  • Table Load: 600 kg

Movement

  • Number of Axes: 3
  • X-axis Travel: 635 mm
  • Y-axis Travel: 510 mm
  • Z-axis Travel: 460 mm

Technical Specification

  • Number of Tools: 20
  • Spindle Power: 17 kW
  • Spindle Speed: 12000 RPM
  • Taper Size: SK 40

Additional Information

  • CNC control: electronic handwheel

  • Operating hours: Power on approx. 13,550 h; Spindle cutting approx. 1,748 h

  • Table: 900 × 560 mm

  • Spindle: 12,000 rpm; SK40 / ISO40; Power approx. 13–17 kW

  • Tool magazine: 20 positions; Automatic double‑arm tool changer

  • Feed rates: Rapid traverse 30 m/min

  • Coolant: Flood coolant system

  • Drives: Digital AC servo drives

  • Electrical: 400 V / 50 Hz / 3‑phase; Rated power 17 kVA

  • Dimensions (approx.): 3000 × 2200 × 2600 mm

  • Other: Machine connected and under power; very low spindle cutting hours for the year; good technical condition

Additional equipment

  • Chip conveyor

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
