Gildemeister - CTX600EDE-TUR-GIL-1998-00005

Name: Gildemeister CTX600E
Brand: Gildemeister
SKU: DE-TUR-GIL-1998-00005
Price: 23000 EUR
Availability: InStock

23,000 €

gindumac price

(Ex works)

get an official quote

Visit the machine

make a counteroffer

Download PDF

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Used Gildemeister CTX600E For Sale | gindumac.com

This Gildemeister CTX600E was manufactured in 1998. It features a turning length of 1000 mm, a spindle bore of 107 mm, and a chuck size of 315/400 mm. The machine offers a spindle speed range up to 3600 rpm and includes a 12-station turret with 6 driven tool stations. Ideal for precise horizontal turning, it supports a maximum turning diameter of 520 mm. Contact us for more information about this machine.

Overview

brand: Gildemeister
year: 1998
MODEL: CTX600E
application type: Turning
Location: Germany
machine type: Horizontal Turning Machine
control unit brand: HEIDENHAIN

Technical Information - Gildemeister CTX600E

Control Unit

Brand: HEIDENHAIN

Additional Equipment

- Noise emission values: 77 dB (continuous sound pressure level)

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Dimensions of machine (lxwxh): 5560x2400x2130 mm or 6600x2400x2130 mm (without chip conveyor) / weight (kg): 8700 kg movement
- - Axes: 2 / cross travel: 320 mm / longitudinal travel: 1097 mm / x-axis travel: 185 + 8 mm / z-axis travel: 500 mm workpiece
- - Max. Turning diameter: 520 mm / turning diameter over cross slide: 370 mm / max. Turning length: 1000 mm / bar capacity: 51 mm / max. Workpiece weight (with tailstock): 180 kg
- - Spindle head: 220 mm / spindle bore: 107 mm / spindle speed range: 18-3600 rpm / drive power 100% duty cycle: 23 kw / max. Torque: 630 nm
- - C-axis speed: < 100 rpm / holding torque: 750 nm / digitization accuracy: <0. 025
- - Tool carrier: universal disk turret / number of tool stations: 12 / max. Driven tools: 6 / drive power 40% duty cycle: 11 kw
- - Automatic indexing with directional logic
- - Quill diameter: 120 mm / quill stroke: 1200 mm / quill taper: 5 mk / quill pressure max: 14 kn
- - Max. Turning diameter: 370 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
