This 3-axis Okuma LB2000EXII MC horizontal turning machine was manufactured in 2013. It features a chuck size of 6 inches, a maximum swing diameter of 580 mm, and a maximum machining diameter of 360 mm. The spindle speed ranges from 50 to 6000 rpm, and it includes a turret head with 12 tool positions. Additionally, it comes with an IRCO MUK-7012 barfeed magazine and Hainbuch SPANNTOP collet chuck. Consider the opportunity to buy this Okuma LB2000EXII MC horizontal turning machine. Contact us for more information.
Overview
- brand: Okuma
- year: 2013
- MODEL: LB2000EXII MC
- application type: Turning
- Location: Czech Republic
- machine type: Horizontal Turning Machine
- availability: Sold
- control unit brand: OKUMA
Technical Information - Okuma LB2000EXII MC
General Data
- Measurements width: 1985 mm
- Measurements depth: 1734 mm
- Measurements height: 2250 mm
- Machine weight: 4050 kg
Control Unit
- Brand: OKUMA
- Model: OSP P300L
Main drive
- Spindle speed range: 50 - 6000 rpm 1/MIN
Movement
- X-AXIS Movement: 260 MM
- Y-AXIS Movement: 100 MM
- Z-AXIS Movement: 350 MM
Additional Equipment
- - Includes Barfeed Magazine: IRCO MUK-7012 (6-70mm/1250mm)
- - Includes Tool Holders (including driven) and Collet Chuck Hainbuch SPANNTOP
Additional Information
- Technical Machine Benefits:
- - Power: 11. 0/7. 5; (15/11; 22/15) kw
- - Rapid traverse x-axis: 25 m/min /rapid traverse y-axis: 12. 5 m/min/rapid traverse z-axis: 30 m/min
- - Chuck size: 6 inch
- - Max. Swing diameter: 580 mm
- - Max. Machining diameter: 360 mm
- - Max. Machining length: 150 mm
- - Number of tool positions: 12
- - Clamping for external machining: 20 x 20 mm / clamping for internal machining: diameter 32 mm
- - Turret : driven tool speed: 45 - 6000 rpm /npower: 5. 5/3. 7 (7. 1/4. 1) kw
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
