This 6-axis REHM COMPACT-ARC 200 VM was manufactured in 2015. It features a robust welding robot cell, operating on 3 × 400 V AC with a mains frequency of 50 Hz. It can handle a maximum workpiece weight of 200 kg and requires 6 bar compressed air. Dimensions are 3990 × 2020 × 2300 mm, weighing 1720 kg. Consider the opportunity to buy this REHM COMPACT-ARC 200 VM welding robot. Contact us for more information.
Overview
- brand: REHM
- year: 2015
- MODEL: COMPACT-ARC 200 VM (2015)+MOTOMAN NX100
- application type: Welding
- Location: Hungary
- machine type: Welding Robot
Technical Information - REHM COMPACT-ARC 200 VM (2015)+MOTOMAN NX100
Dimensions
- Machine Height: 2300 mm
- Machine Length: 3990 mm
- Machine Weight: 1720 kg
Movement
- Number of Axes: 6
Additional Information
Operating voltage: 3 × 400 V AC
Mains frequency: 50 Hz
Connected load: 3 × 63 A
Required compressed air: 6 bar; 100 l/min
Maximum workpiece weight: 200 kg
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
