Front view of Battenfeld SmartPower 110/350  machine

Battenfeld SmartPower 110/350

Battenfeld - SmartPower 110/350

2015

Sold

Do you have further questions? Contact us.

sales contact

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

whatsapp
Click to chat on WhatsApp

This Battenfeld SmartPower 110/350 Injection moulding machine was manufactured in Germany in 2015. It shows 153 production hours, practically new. It is equipped with an UNILOG B6 control unit. The machine works with a clamping force 1100 kN and includes an air dryer DRYMAX E30. Machine in perfect condition.

Overview

  • brand: Battenfeld
  • year: 2015
  • MODEL: SmartPower 110/350
  • production hours: 153
  • application type: Injection Moulding
  • Location: Poland
  • machine type: Injection Moulding Machines
  • availability: Sold
  • GINDUMAC ID: PL-INJ-BAT-2015-00001

Technical Information

General Data

  • Measurements width: 4500 mm
  • Measurements depth: 1500 mm
  • Measurements height: 2100 mm
  • Machine weight: 4500 kg

Injection Unit

  • Screw diameter: 40 mm
  • Injection pressure: 1595 bar

Clamping unit

  • Clamping force: 1100 kN
  • Opening stroke: 550 mm
  • Distance between bars: 520 x 470 mm
  • Mould height min: 296 x 296 mm
  • Ejector stroke: 150 mm

Media

  • Main electronic connection: 400V / 50Hz

    Additional Equipment

    • - Air dryer DRYMAX E30
    • - Wittmann Battenfeld Smart Power 110-150 Injection Molding Machine + UNILOG B6P Control
    • - Wittmann Battenfeld Drymax E30-50-M-C-180 dryer
    • - Wittmann Battenfeld Freedmax S3-NET feeder
    • - Thermostat Wittmann Battenfeld TemPro Plus D TP + D-S-1: 180

    Additional Information

      Machine Benefits

      • Technical Machine Benefits:
        • - Min. Mould mounting height – 250 mm
        • - Opening force – 53 kn
        • - Max. Platen distance – 800 mm
        • - Max. Mould weight – 1100 kg
        • - L/d ratio: 22
        • - Injection volume: 220 cm3
        • - Max weight of injection: 160. 6 g
        • - Min. Mold height: 250 mm
        • - Max platen distance: 800 mm
        • - Opening stroke / force: 550 mm / 53 kn
      • Qualitative Machine Benefits:
        • - Machine is like a new.
        • - Not used in production
        • - Full documentation available.

    *There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
