Gildemeister Twin 32 Lathe machine

This Gildemeister Twin 32 Lathe machine was built in Germany in 2001. This machine is operated through a Siemens Sinumerik 840D control unit. It works with a spindle speed up to 8000 rpm. It includes a Barload magazine FMB as additional equipment. The machine is in very good condition.

Overview

brand: Gildemeister
year: 2001
MODEL: Twin 32
production hours: 38000
application type: Turning
Location: Slovenia
machine type: Turn-Mill Centre
control unit brand: SIEMENS

Technical Information - Gildemeister Twin 32

General Data

Machine weight: 6000 kg

Control Unit

Model: Sinumerik 840D
Brand: SIEMENS

Main drive

Number of spindles: 2
Spindle speed range: 8000 1/MIN
Number of axis: 7

Movement

X-AXIS Movement: 220 mm
Y-AXIS Movement: +- 50 mm
Z-AXIS Movement: 320 mm

Turret

Number of turrets: 2

Media

Power consumption: 50 kva

Additional Information

Additional equipment

Barload magazine FMB

Machine Benefits

Qualitative Machine Benefits

Good condition
Only oil has been used as coolant
All books and manual
20x fixed tool holders + 20x live tool holders
C axis on both spindles
Sub spindle high pressure coolant cleaning
High pressure coolant pumps with coolant filtration
Live tools on both turrets
Linaer x axis for high precision
Hainbuch bzi 42 collets clamping system

Technical Machine Benefits

Spindle to spindle distance: 580 mm
Spindle 1 bar diameter max. : 36 mm
Spindle 2 bar diameter max. : 36 mm
Slide 1 (top) plan path x / longitudinal path z: 220/ 320 mm
Slide 2 (low) plan path x / longitudinal path z: 120/ 345 mm
Slide 2 (low) rapid traverse x / y / z: 30/30 m / min
Slide 1 (top) rapid traverse x / y / z: 30/15/30 m / min

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
