These 4-axis Starrag Heckert HEC 500 H/V were manufactured in 2008 and 2009. They features a swivelling head configuration, with an X-axis travel of 800 mm, Y-axis travel of 800 mm, and Z-axis travel of 680 mm. The machines include a pallet size of 500 x 500 mm and a maximum load per pallet of 1000 kg. If you are looking to get high-quality machining capabilities, consider these Starrag Heckert HEC 500 H/V horizontal machining centres we have for sale. Contact us for further details.
Overview
- brand: Starrag Heckert
- year: 2008
- MODEL: HEC 500 H/V
- application type: Milling
- Location: Germany
- machine type: Horizontal Machining Centre
- control unit brand: SIEMENS
Technical Information - Starrag Heckert HEC 500 H/V
Control Unit
- Control Brand: SIEMENS
- Control Model: SINUMERIK 840D Powerline
Dimensions
- Table Load: 1000 kg
Movement
- Number of Axes: 4
- X-axis Travel: 800 mm
- Y-axis Travel: 800 mm
- Z-axis Travel: 680 mm
Technical Specification
- Max. Tool Weight: 25 kg
- Number of Tools: 80
- Spindle Power: 37 kW
- Spindle Speed: 10000 RPM
- Taper Size: SK 40
Additional Information
Package: 2 horizontal machining centers + shared pallet storage system
STARRAG HECKERT HEC 500 H/V (2008)
Control: Siemens SINUMERIK 840D Powerline
Head: Swivelling H/V head (Horizontal/Vertical)
Pallet size: 500 x 500 mm
Travels: X 800 mm / Y 800 mm (vertical position) / Z 680 mm
Rapid traverse: 60 m/min
Spindle power: 37 kW
STARRAG HECKERT HEC 500 H (2009)
Control: Siemens SINUMERIK 840D Powerline
Pallet size: 500 x 500 mm (DIN 55201)
Travels: X 800 mm / Y 650 mm / Z 680 mm
Rapid traverse: 60 m/min
Spindle torque: 82 Nm
Max. tool weight: 25 kg
Max. tool diameter: 80 mm (160 mm with free adjacent places)
NC rotary table (B-axis): 360,000 x 0.001°
Note: Tool breakage detection system is out of service
Additional equipment
Fastems FPC 1500 Linear Pallet Pool (shared by both machines)
Automation: Both machines connected to the Fastems FPC 1500 LPP
For HEC 500 H (2009):
Coolant system with paper band filter
Internal coolant supply, 50 bar
Chip conveyor
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
