➤ Used WITTMANN TM Xpress 270/2250 Unilopg B6P For Sale

This WITTMANN TM Xpress 270/2250 Unilopg B6P was manufactured in 2013. It features a screw diameter of 55 mm, a maximum screw speed of 220 rpm, and a clamping force of 2700 kN. The machine offers a maximum shot weight of 498 g and an injection speed of 980.0 cm³/s. It includes a Wittmann CNC 8 control for enhanced operation. Contact us for more information about this machine.

Overview

brand: WITTMANN
year: 2013
MODEL: TM Xpress 270/2250 Unilopg B6P
application type: Injection Moulding
Location: Austria
machine type: Hydraulic Injection Moulding Machine

Technical Information - WITTMANN TM Xpress 270/2250 Unilopg B6P

Injection Unit

Screw diameter: 55 mm
Shot weight: 498 g
Injection pressure: 2070 bar
Screw speed: 220 rpm

Clamping unit

Clamping force: 2700 kN
Opening stroke: 600 mm
Mould height min: 200 mm
Mould height max: 600 mm
Ejector stroke: 200 mm
Ejector force for / back: 130 kN

Additional Information

Additional Equipment:

Screw barrel insulation for energy savings
Additional packages welded and dimensioned, including factory markings A4
Screw barrel diameter 55 mm, screw length 22 D
Screw core cooling (water)
Robot integration interface including signal conversion
Hazardous area protection interface
CE/GS conformity, EN ISO 14120
Various plugs/sockets (16A, 32A) for motor and heater

Extra information

Color coding: Paint: RAL 5002, Cover hoods: RAL 7047, X-beam, Y-beam, Z-beam: RAL 7047
Control: Wittmann CNC 8 control mounted on the Z-beam
Emergency stop block
Wittmann R8 touchscreen remote control (removable)
Control number: CNC 8
Calculated displacement: 520 cm³
Max. injection speed: 980 cm³/s
Tiebar table clearance (W x H): 630 x 630 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
