HARTFORD HMC-10

Photo Gallery

HARTFORD - HMC-10PT-MIL-HAR-2017-00001

Sold

Do you have further questions? Contact us.

Borja Garcia

+34 679 019 350

b.garcia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
Hartford HMC-10 Horizontal Machining Center

This Hartford HMC-10 Horizontal Machining Center was built in 2017 in Taiwan and has been working for only 4000 hours. Equipped with a FANUC Hartol Expert 3 Control unit, this machine can operate with a spindle speed range up to 10000 rpm. 10 cones for tool clamping, and auxiliary benches are included as additional equipment.

Overview

brand: HARTFORD
year: 2017
MODEL: HMC-10
production hours: 4000
application type: Milling
Location: Portugal
machine type: Horizontal Machining Centre
control unit brand: FANUC

Technical Information - HARTFORD HMC-10

Control Unit

Control Brand: FANUC
Control Model: Hartol Expert 3

Dimensions

Machine Depth: 4500 mm
Machine Height: 3500 mm
Machine Weight: 27000 kg
Table Length: 1000 mm
Table Width: 1000 mm

Movement

X-axis Travel: 1300 mm
Y-axis Travel: 1150 mm

Technical Specification

Max. Tool Weight: 25 kg
Spindle Speed: 10000 RPM
Through-spindle Coolant: Yes

Additional Information

Additional equipment

15 tools

Machine Benefits

Technical Machine Benefits

Internal cooling
When changing pallets / tables the differences are never greater than 0. 02mm. In most cases the difference is zero
The compensation of the table / tool is done automatically. It is mandatory to have a controlled environment to be successful.
10 cones for tool clamping
Auxiliary benches

Machine History

Industries

Automotive

End product

Moulds

Material type

Steel

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
