Nicolas Correa Prisma 20
Nicolas Correa - Prisma 20
2004
Do you have further questions? Contact us.
Borja Garcia
+34 679 019 350
b.garcia@gindumac.com
- GINDUMAC
- Products
- Machine Tools
- Nicolas Correa Prisma 20 Milling machine
This Nicolas Correa Prisma 20 Milling machine was manufactured in the year 2004. It is equipped with a Heidenhain iTNC 530 control unit and has 4 axis. The machine has a spindle speed of 550-4000 rpm.
Overview
- brand: Nicolas Correa
- year: 2004
- MODEL: Prisma 20
- application type: Milling
- Location: Spain
- machine type: Milling Machine
- availability: Sold
- control unit brand: Heidenhain
- GINDUMAC ID: ES-MIL-NIC-2004-00001
Technical Information
General Data
- Machine weight: 14000 kg
Control Unit
- Brand: Heidenhain
- Model: iTNC 530
Main drive
- Number of spindles: 1
- Spindle speed range: 550-4000 1/MIN
Movement
- X-AXIS Movement: 2000 mm
- Y-AXIS Movement: 1000 mm
- Z-AXIS Movement: 1000 mm
Workpiece
- Workpiece weight: 3500 kg
Table
- Outer length: 2000 mm
- Outer width: 900 mm
- Number of tslots: 5
- Distance between: 200 mm
Tools
- Type of tool holder: ISO-50
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
