This Quaser HX404 Horizontal Machining center was manufactured in the year 2016 in Taiwan. It is equipped with a Fanuc 31 LB control unit. The machine has a spindle speed of 15000 rpm.
Overview
- brand: Quaser
- year: 2016
- MODEL: HX404
- application type: Milling
- Location: Germany
- machine type: Machining centers (horizontal)
- availability: Sold
- control unit brand: FANUC
Technical Information - Quaser HX404
General Data
- Measurements width: 2365 mm
- Measurements depth: 4915 mm
- Measurements height: 2895 mm
- Machine weight: 10500 kg
Control Unit
- Brand: FANUC
- Model: 31 LB
Main drive
- Spindle speed range: 15000 1/MIN
- Spindle motor power: 26 kW
Movement
- X-AXIS Movement: 560 mm
- Y-AXIS Movement: 640 mm
- Z-AXIS Movement: 640 mm
- B-AXIS Movement: 360º MM
Tools
- Type of tool holder: BT 40
Additional Equipment
- - pallet is included
- - No zero point clamping systems included
- - 1x hydraulic power unit (motor)
Additional Information
- Technical Machine Benefits:
- - Number of tool magazine positions 60
- - Tool changing time [sec] 1. 4 max. Tool diameter [mm] 76 max. Tool diameter with free adjacent space [mm 125 tool length max. [mm] 350 tool weight max. [kg] 7
- - Coolant system
- - Volume of coolant tank [l] 650 internal coolant supply pressure [bar] 20 internal coolant supply [l/min] 25 jet cooling pressure [bar] 3 jet cooling [l/min] 60 chip flushing pressure [bar] 1. 5 chip flushing [l/min] 25 coolant spray gun yes
- - Heat compensation
- - Temperature-controlled oil cooling system for main spindle yes cooled ball screws
- - Lectrical connected load: 41 kva
- - Required pneumatic connection [bar] 6 hydraulic unit yes hydraulic oil tank [l] 200
- - Pallet size: 400 x 400 mm
- Qualitative Machine Benefits:
- - Maximum swing diameter: 630 mm
- - Pallet change time: 5,5 s
- - Maximum loading weight: 400 kg
- - Maximum height on pallet: 900 mm
- - Main spindle torque max. [nm]: 177
- - Tool holding system: bt40fc
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
